- Power: 2500/4000W
- Daylight-balanced (6000K) spotlight
- Single ended line of Metal-Halide lamps (HMI*)
- Front UV protective glass with safety wire mesh
- Optional spread lenses for beam angle variations
- Sturdy die cast aluminum construction
- Includes: ballast, power cable, barndoors, case
- DMX512 control optional
HMI PAR 6000 watts kit
- Power: 6000W
- Daylight-balanced (6000K) spotlight
- Single ended line of Metal-Halide lamps (HMI*)
- Front UV protective glass with safety wire mesh
- Optional spread lenses for beam angle variations
- Sturdy die cast aluminum construction
- Includes: ballast, power cable, barndoors, case
- DMX512 control optional
€13'99900
Available only on pre-order with delivery time of 8-12 weeks.
Powerful daylight-balanced light source
The Cinelight PAR HMI lights are best suited for motion picture, events and TV productions where the maximum light output is required. PAR fixtures are recommended to be used for lighting background elements or diffused / bounced into a white reflector panel to act as a soft fill light for talents (PAR lamps are too hard sources to be used for lighting faces directly).
Optional spread lenses for beam angle variations
The Cinelight PAR HMI lights come with clear, UV protective glass in front topped up by a safety wire mesh. Optional drop-in spreader lenses can be used to fine-tune the light output from wide flood to narrow spot variations, in order to obtain the optimal beam angle. The spreader lenses affect both the shape and angle of the beam and are available to be purchased separately.
Fully die cast aluminum housing
The Cinelight PAR HMI is using a series of aluminum extrusions and aluminum corrosion castings for the housing to quickly dissipate the heat that comes from the light bulb, therefore increasing the lamp's life. The amount of time needed for the fixture to cool down is reduced so it's easier to handle.
High speed & flicker-free HMI ballast
As with any HMI fixture, the Cinelight HMI PAR lights require a ballast in order to function. The Cinelight HMI electronic ballast complies to the industry's high demanding requirements: flicker free, very low noise, high output and stable long-term operation. The ballast features a rugged and compact design for easy handling on the field.
The ballast employs the ALF technology (Active Line Filter) which minimizes the power line interference, providing a higher Power Factor for a more efficient power use. This translates to a consistent color temperature and flicker-free dimming, despite power line voltage fluctuations.
The dedicated high-speed function of the ballast drives the lamp to 300Hz or 1kHz to ensure a flicker-free image in slow motion shootings.
The ON/OFF power switch on the ballast control panel allows for hot re-striking, while the dedicated dimming knob vary the power down to 50%.
Safety circuits such as over-voltage, over-temperature and short-circuit protection provide a safe and reliable operation.
Wide range of applications in the film industry
These lighting instruments are commonly used to light large setups at night, giving a little more depth to the scenes, and also in situations requiring a far reaching, intense beam. Whenever punch or bounce light is required on a set, the Cinelight PAR is the optimal solution. The daylight-balanced output provided by the HMI fixtures is an essential artificial lighting source for most productions.
Transport case included
For easy transportation and safe storage, a hard plywood case is included which accommodates the kit's components: HMI PAR lamp head, electronic ballast, power cable and metal barndoors.
Specifications
HMI - Fixture
Beam type | spot |
Rated power | 6000 watts |
Lamp type | Single-End |
Lamp socket | G38 |
Color temperature | 6000K |
Lens type | Interchangeable |
Spot-Flood selector type | Mechanical |
Yoke mount | Spigot 28mm pin |
Housing color | Gray & blue |
Housing material | Aluminum |
Lamp head dimensions | 1050 x 700 x 610 cm |
Lamp head weight | 31.3 kg |
HMI - Ballast
Ballast power | 6000 watts |
Ballast line power | 26A-38A |
Ballast nominal current | 6900VA |
Ballast operation voltage | 180-265VAC |
Ballast frequency | 50-60 Hz |
Ballast current characteristics | Square wave, 75Hz |
Ballast power factor | 0.98 |
Ballast dimming range | 100%-50% |
Ballast starting | Hot re-strike |
DMX control | Optional |
DMX connectors type | XLR-3P |
ballast power cable length | 15 m |
Power cord total length | 5.0 m |
Power connector type | CEE 2P+E |
Ballast dimensions | 24 x 37 x 45 cm |
Ballast weight | 26 kg |
Ballast protection class | IP32 |
